12 Steps To Replace iPhone 4 Earpiece Speaker -Replace a blown-out earpiece speaker in your iPhone 4

Step 1

First, we need to prepare the repair tool kit and earpiece replacement part

Before disassembling your iPhone 4, be sure it is powered off

And then use a SIM card eject tool to eject the SIM card and its holder.

Remove the SIM card and its holder from the iPhone

Step 2

Remove the two 3.6 mm Pentalobe or Phillips #000 screws next to the dock connector.

Your iPhone 4 rear cover may have either two #000 Phillips screws or Apple's 5-Point "Pentalobe" screws. Check which screws you have, and ensure you also have the correct screwdriver in order to remove them.

As you can see, the iPhone 4 that we used here is with two 3.6 mm Pentalobe screws,so we use the Pentalobe screwdriver here

(Our Repair Tools provides the tools and screws needed to replace the Pentalobe screws with Phillips screws.)

Step 3

Push the rear panel toward the top edge of the iPhone

Pinch the rear panel with your fingers and lift it away from the iPhone. Or you can use a Suction Cup in case of damage the plastic clip that attached to the rear panel.

Step 4

Remove the single 2.5 mm Phillips screw connecting the battery connector to the logic board

Step 5

Use a plastic opening tool to pry the battery connector up from its socket on the logic board Or use the clear plastic pull-tab to gently lift the battery out of the iPhone

Remove the metal clip covering the antenna connector

Be very careful when you do this, or you may break the logic board entirely

Step 6

Remove two screws:One 1.2 mm Phillips;One 1.6 mm Phillips

And then remove the thin steel dock connector cable cover from the iPhone

Use a opening tool to gently pry the dock cable connector up off the logic board from both short ends of the connector

Remove the 1.9 mm Phillips screw securing the bottom of the logic board to the inner case

Step 8

Remove five screws connecting the Wi-Fi antenna to to the logic board:

One 2.3 mm Phillips

Two 1.6 mm Phillips

One 1.4 mm Phillips

One 4.8 mm Phillips

Use a opening tool to lift the top edge of the Wi-Fi antenna away from the logic board

Use the tip of a tweezer to pull the Wi-Fi retaining clips away from the inner frame

Remove the Wi-Fi antenna from the iPhone

Step 9

Use a opening tool to carefully lift the rear camera connector up off its socket on the logic board

And remove the rear camera.

Step 10

Remove two screws connecting the vibrator to to the logic board

Step 11

Use a screwdriver to remove the 4.8 mm standoff near the headphone jack

Carefully remove the logic board from the iPhone

Step 12

 Now we can see the earpiece speaker here.

Use the edge of a plastic opening tool to pry the earpiece speaker off the adhesive securing it to the front panel

Remove the earpiece speaker and replace it with the new one

Follow these instructions in reverse order while reassemble your device
